The Domain Name System (DNS) (Network Foundations) acts as the Internet's GPS transforming memorable Domain Names (i.e. destination name) to IP Addresses (i.e. longitude and latitude coordinates) which computers use to communicate.

Domain Names for the same reason that destination names, in applications like Google Maps exist, trying to navigate a city utilising the exact longitude and latitude coordinates for a location would be tedious and cumbersome, and therefore DNS was created as an easily-to-remember human-readable format.

The DNS Process¶

Stage	Action Performed	Description
1	Computer Asks For Directions (DNS Query)	Domain Name (e.g. google.com) is entered and the computer checks the memory (cache) to see if it recalls the IP Address from a previous visit. In the event, it does not it reaches out to a DNS Resolver usually provided by the ISP (Internet Service Provider).
2	DNS Resolver Checks Its Map (Recursive Lookup)	The DNS Resolver, which also has it's own cache, in the event it doesn't have the IP Address from there it begins the process of searching the DNS Hierarchy. It queries its Root Name Server. (e.g. the librarian of the internet.)
3	Root Name Server Points The Way	Root Server doesn't know the exact address but knows the TLD Name Server responsible for the end of the domain (e.g. .com, .org, .gov, etc) does, and points the DNS Resolver to the correct TLD Name Server.
4	TLD (Top-Level Domain) Name Server Narrows Down	The TLD Name Server (which can be compared to a regional map) knows which Authoritative Name Server is responsible for the specific domain trying to be found, and continues to send the DNS Resolver there.
5	Authoritative Name Server Deliver's IP Address	The Authoritative Name Server is the final destination (i.e. the exact street address) locates the correct IP Address and sends back to DNS Resolver.
6	DNS Resolver Returns The Information	The DNS Resolver receives the IP Address and provides it back to the computer, which also caches it in the event it needs to revisit it again.
7	Computer Connects Using IP Address	Now that the Computer knows the IP Address from the DNS Resolver it connects to the web server hosting the website.

The Hosts File¶

The Hosts file is simply a text file which is used to map hostnames to IP Addresses providing a manual local method of Domain Name Resolution which completely bypasses the DNS process.

The DNS Process automates the process of translation from Domain Names to IP Addresses, the hosts file allows for direct local overrides.

OS Host File Locations¶

• Windows: *C:\Windows\System32\drivers\etc\hosts
• MacOS: /private/etc/hosts
• Linux: /etc/hosts

Host File Format:
<IP Address> <Hostname> [<Aliases> ...]

Example:
127.0.0.1 localhost
192.168.1.10 devserver.local

• Administrator/Root Privileges are required to edit host files.
• Any Changes are immediate without requiring a system restart.

Common Use Cases for Editing Host File¶

• Development & Troubleshooting
• Blocking Specific Websites (e.g. Unwanted Websites by redirecting their domains to non-existent IPs (e.g. 0.0.0.0))
• Redirecting a Domain to local server for development purposes
• Verifying Connectivity by specifying an IP Address.

DNS Zones¶

In DNS a zone is a specific part of the domain namespace that a specific entity or individual (i.e. administrator) manages. The zone acts as a virtual container for a set of domain names in relation to the domain itself (e.g. mail.example.com in relation to the domain example.com).

Example of DNS Zone¶

The zone file (similar to the hosts file on a user's computer) resides on a DNS Server and defines the resource records of the domain, providing information for translating Domain Names into IP Addresses.

Example of DNS Zone File¶

$TTL 3600 ; Default Time-To-Live (1 hour)
@       IN SOA   ns1.example.com. admin.example.com. (
                2024060401 ; Serial number (YYYYMMDDNN)
                3600       ; Refresh interval
                900        ; Retry interval
                604800     ; Expire time
                86400 )    ; Minimum TTL

@       IN NS    ns1.example.com.
@       IN NS    ns2.example.com.
@       IN MX 10 mail.example.com.
www     IN A     192.0.2.1
mail    IN A     198.51.100.1
ftp     IN CNAME www.example.com.

Explanation of DNS Zone File Key Elements¶

The zone file defines the Authoritative Name Servers (NS Records), Mail Server (MX Record), and IP Addresses (A Records) for various hosts within the example.com domain.

DNS Record Types¶

DNS Zone File Classifications¶

• IN stands for Internet. (Indicates record applies to the Internet Protocol Suite (IP))

Other Classifications Rarely used in Modern DNS Configurations¶

• CH stands for ChaosNet.
• HS stands for Hesiod.

Why DNS Matters For Web Reconnaissance¶

The DNS is a critical component of the target's infrastructure which can be leveraged for vulnerabilities.

Uncoverable Vulnerabilities in DNS¶

No Exercises for this section.¶
